RO and under-sink systems
Place the UVC LED module after suitable filtration and near the delivery point. Check peak dispense flow, tube size, residual pressure and available installation space.
Compact POU platform · OEM integration
EC Series UV LED Water Purifier Modules for POU and OEM Integration
Compare EC-10, EC-11, EC-12 and EC-13 as compact UVC LED disinfection modules for ultraviolet water purifiers, RO systems, dispensers, faucets and OEM water appliances. This page helps engineering and purchasing teams shortlist by flow duty, plumbing, control method and linked model evidence.
EC-10
EC-11
EC-12
EC-134 compact modelsDifferent integration roles
POU applicationsRO, dispenser and appliance
Model-specific test reportsLinked to each model
OEM-ready selectionApplication-team support
Application fit
Which EC module fits your equipment?
The broader point-of-use UVC LED water purifier solutions page explains where terminal treatment is used. Our application team maps each EC module to the host product’s hydraulic, electrical and integration requirements.
Dispensers and faucets
For intermittent terminal flow, coordinate start threshold, voltage version, harness and thermal environment with the appliance controller and duty cycle.
Branded water appliances
For OEM or private-label programs, shortlist the hydraulic core first, then validate connector, labeling, packaging, compliance documents and production sample.
Model comparison
Compare EC-10, EC-11, EC-12 and EC-13
Current specifications, integration features and linked model reports are presented together for easy comparison.
Standard compact POU
EC-10
For RO systems, dispensers and inline OEM equipment that need a compact 4 L/min-class module.
- Up to 4 L/min
- 1/4″ tubing
- 7 W input
- 140 mW UVC output
- 12 V / 24 V versions
- L70: 3,000 h
Low-flow POU
EC-11
A slim inline module for low-flow terminal applications in RO systems, dispensers and water appliances.
- 1.5 L/min
- 1/4″ quick-connect
- 12 V / 24 V versions
- ≤1.8 W input
- 28 mW UVC output
- L70 ≥4,000 h
Integrated flow switch
EC-12
For terminal POU equipment that needs automatic flow activation and a choice of quick-connect sizes.
- Up to 4 L/min
- 1/4″ or 3/8″
- 4.8 W input
- 85 / 115 mW variants
- Integrated flow switch
- 5,000 h lifetime
Compact inline option
EC-13
A compact 22 × 97 mm inline platform for low-flow appliance integration.
- 2 L/min
- 1/4″ quick-connect
- 12 V / 24 V versions
- ≤2 W input
- 55 mW UVC output
- L70 ≥5,000 h
| Model | Best-fit role | Published flow | Connection / control | Key configuration |
|---|---|---|---|---|
| EC-10 | Standard compact OEM POU | Up to 4 L/min | 1/4″ tubing; separate 12 V / 24 V versions | Good starting point where compact size and a verified 4 L/min duty align. |
| EC-11 | Low-flow terminal equipment | 1.5 L/min | 1/4″ quick-connect; 12 V / 24 V versions | Slim 28 mW platform for compact appliance layouts. |
| EC-12 | Flow-activated POU integration | Up to 4 L/min | 1/4″ or 3/8″; integrated flow switch | Integrated flow switch with 85 / 115 mW optical-output options. |
| EC-13 | Compact inline appliance integration | 2 L/min | 1/4″ quick-connect; 12 V / 24 V versions | Compact 22 × 97 mm, 55 mW platform for low-flow integration. |
Our application team matches peak flow, source water, installation, electrical version and model documents to the complete appliance.
Engineering selection
How to choose an EC UVC LED module
Share these four application inputs and our team will match the EC model and configuration to the real host equipment.
1. Peak flow and UVT
Use actual peak dispense flow—not only daily volume. Low UV transmittance, turbidity or fouling can reduce the optical margin available in the chamber. Learn how to size by flow rate and UVT.
2. Connection and envelope
Our team aligns tube outside diameter, inlet and outlet orientation, bend radius, service access and the available appliance space.
3. Voltage and control
Separate 12 V and 24 V versions are available across the EC range. We align flow activation, connector, wiring and the host controller’s power budget.
4. Pretreatment and duty cycle
UVC works with upstream filtration or conditioning as part of the complete water-treatment path. We review on/off frequency and the enclosure’s thermal environment.
Model test reports
View specifications and available evidence by model
Each SGS microbiological result is presented with its specific EC model, organism, test flow and stated report conditions.
EC-10 test scope
SGS report NBF23-0000146-01 records >99.99% reduction of E. coli CICC10389 at 4 L/min under the stated test conditions.
Open the EC-10 SGS reportEC-11 test scope
SGS report NBF25-0001850-01 records >99.999% reduction of E. coli ATCC25922 at 1.5 L/min.
Open the EC-11 SGS reportEC-12 test scope
SGS report NBF25-0001850-02 records >99.999% reduction of E. coli ATCC25922 at 4 L/min.
Open the EC-12 SGS reportEC-13 documentation
Current EC-13 specifications, drawing and electrical documentation are available from Agua Topone for project integration.
Request the EC-13 document setThe EC Series electrical-compliance file and model test reports are available for document review. Our team will assemble the files relevant to the selected model and target market. See how to read model-specific SGS test results and the buyer’s guide to certification and test documents.
OEM workflow
OEM integration and sample validation checklist
Agua Topone’s OEM/ODM integration support can cover more than a part number. The handoff is stronger when commercial and engineering inputs arrive together.
- Peak and normal flow, UVT or available water-quality data
- Tube size, pressure, installation envelope and orientation
- Voltage version, connector, harness and control logic
- Duty cycle, start frequency and thermal environment
- Target market, document list, labeling and packaging needs
- Engineering sample plan and acceptance criteria before production
Engineering resources
EC Series technical resources
Use these guides to resolve an input before requesting a final model. They connect the EC family to the same engineering knowledge base used across the website.
Install UVC LED after an RO system
Compare tanked and tankless placement, flow direction and terminal-point installation.
Read the RO integration guide →Flow-rate validation
Understand why peak flow and real hydraulic conditions matter to model selection.
Review flow-rate validation →What L70 lifetime means
Separate LED output maintenance from a simple on/off service-life claim.
Understand L70 and driver life →Private-label supplier checklist
Turn technical files, samples and change control into a practical sourcing review.
Open the buyer checklist →Selection questions
EC Series FAQ
How does an EC module fit into a complete water purifier?
EC products integrate into a host appliance or water-treatment system and work with its filtration, enclosure, power control and plumbing. Agua Topone supports model selection and integration review for the complete product design.
How do EC-10 and EC-12 differ?
Both serve applications up to 4 L/min. EC-12 adds an integrated flow switch and offers 1/4″ or 3/8″ quick-connect options, while EC-10 is a standard compact platform with 1/4″ tubing. Our team matches the voltage and configuration to the appliance.
How are SGS results presented for EC models?
Each SGS microbiological result is linked to the named model, test organism, flow and stated conditions, with the applicable report available for review.
What should I send for an OEM quotation?
Send peak flow, water-quality data or UVT, tube size, pressure, installation envelope, voltage, control method, target market, expected volume and required documents. Photos or a layout drawing help the engineering review.
Can connection, cable or branding be customized?
Selected mechanical, electrical, labeling and packaging items may be discussed by project and volume. Any change that can affect performance requires engineering review and sample validation before production.
EC Series selection
Send the appliance inputs for model matching
Share flow, UVT or source-water data, voltage, tube size and installation envelope. Our application team will prepare a model-specific technical shortlist.
