LOW-FLOW POU UVC LED MODULE · 0.4 GPM
EC-11 Low-Flow UVC LED Water Purifier Module
A slim low-flow module for countertop, dispenser and compact OEM appliances.
EC-11 is selected from its 1.5 L/min model basis, water conditions, quick-connect interface, 12 V or 24 V version and the exact SGS report conditions.
1.5 L/min Model flow basis · 0.4 GPM
≤1.8 W Input power
28 mW UVC radiant output
Ø17 × 126 Slim product envelope · mm
PRODUCT ROLE
Low-flow POU treatment for compact appliance layouts.
EC-11 is intended for countertop purifiers, dispensers and other low-flow drinking-water appliances, with flow, UVT, water quality and integration matched to the host product.
APPLICATION FIT
Fit low-flow performance into compact appliance layouts.
- Flow matching: our application team matches the model to the highest realistic draw and target operating condition
- Water review: we review UVT, turbidity, hardness, iron and the appropriate pretreatment
- Mechanical fit: we align pressure, connection, flow direction, mounting and service clearance
- Electrical fit: we select the suitable supply, appliance controls and flow-activation configuration
- Project documents: we prepare the relevant drawing, model report and market documents for review
Water dispensers
On-demand treatment where the real draw remains within the 1.5 L/min basis.
Compact terminals
Slim POU integration using the specified quick-connect interface.
OEM appliances
Custom equipment with confirmed voltage version, cable, terminal and service plan.
ENGINEERING DATA
Specifications for model selection.
The current drawing, datasheet and manual are available for project review. Our team will align them with the quoted configuration.
01
DIMENSION DRAWING EC-11 mechanical drawing
Hydraulic & mechanical
Fit the model to the water path.
- Maximum design flow rate
- 1.5 L/min
- Maximum inlet pressure
- 0.45 MPa
- Inlet / outlet
- 1/4-inch standard quick-connect
- Product dimensions
- Ø17 × 126 mm
- Net weight
- 20 g
- Terminal pull-out force
- ≥30 N
- Wire / terminal
- 160 ±5 mm with XHB2.54-2P terminal
Electrical & optical
Use the correct powered version.
- Input voltage
- 12 V DC or 24 V DC model version
- Input power
- ≤1.8 W
- UVC radiant output
- 28 mW
- UVC wavelength
- 270–280 nm
- L70 service basis
- ≥4,000 hours
- Test environment
- TC 22°C
04
ELECTRICAL & OPTICAL DATA Product parameters
| No. | Parameter | Symbol | Value | Unit |
|---|---|---|---|---|
| 01 | Input voltage | VIN | 12 / 24 | V |
| 02 | Input power | W | ≤1.8 | W |
| 03 | UVC radiation power | Φe | 28 | mW |
| 04 | UVC peak wavelength | WLP | 270–280 | nm |
| 05 | Lifetime test | L70 | ≥4,000 | h |
Measurement and version note
Product test environment is TC 22°C. Peak-wavelength and radiant-power measurement errors are ±3 nm and ±10%. The 12 V and 24 V entries are different model versions.
OEM INTEGRATION REVIEW
Protect the slim module with correct control and cable routing.
Our application team aligns tube size, pressure, mounting orientation, shielding, power version, terminal, host controls and service access with the complete appliance.
- 01 Define water conditions
Peak flow, UVT, turbidity, temperature and upstream treatment.
- 02 Match mechanical fit
Pressure, connection size, flow direction, mounting and service clearance.
- 03 Select electrical version
Supply voltage, host-appliance logic, flow activation and safe cable routing.
- 04 Assemble project documents
Match the exact model report and compliance documents to the target project.
CIRCUIT REFERENCE
Review the 12 V / 24 V circuit diagram.
Use the applicable model document when finalizing protection, connection and host-appliance logic.
PACKAGING
Keep transport and packaging criteria in the review.
The packaging reference supports review together with the vibration and drop-test criteria below.
MODEL-SPECIFIC EVIDENCE
99.99% E. coli reduction recorded in the available EC-11 SGS report under its stated flow and water conditions.
The report presents the model flow and water conditions behind this result; our team aligns them with UVT, turbidity and appliance integration.
Open model test reportModel-specific results with clear test conditions.
The report identifies the model, organism, flow and water conditions behind the performance result.
Documents organized by project purpose.
Performance reports and compliance documents are listed independently for straightforward review.
Factory Test Items and Acceptance Criteria.
The table below lists the factory test items and acceptance criteria for the specific model.
The table below lists the factory test items and acceptance criteria for EC-11, including dry-burning and packaging tests.
No. Test item Test method and criteria
01 Tensile test
Terminal-to-wire tensile force ≥30 N for 1 minute without loosening; welded wire-to-module tensile force ≥35 N without defects within 10 seconds.
02 Dielectric withstand voltage
1500 V / 50 Hz AC is applied between the live part and housing for 1 minute; the test sample remains undamaged.
03 Sealing test
Static pressure is held at 0.4 MPa for 5 minutes without air leakage.
04 Pressure resistance
Static water pressure is increased to 0.6 MPa within 5 minutes at a rate of ≤0.4 MPa/s and held for 15 minutes to check module water tightness.
05 Burst test
Water pressure is raised to 0.8 MPa within 70 seconds, held for 5 seconds and released; appearance, mechanical and electrical performance remain normal.
06 Cyclic pressure
10,000 repeated cycles at 0–0.45 MPa with a 2-second pressure rise are used to observe module water tightness.
07 Dry-burning test
The water purification device operates powered on without water for 24 hours; the module remains undamaged and all functions remain available.
08 Freezing test
The water-filled, blocked module is placed at −18°C for 48 hours and then thawed naturally; sealing performance remains normal.
09 Low-temperature storage
The sample is stored at −30°C ±2°C for 72 hours and recovered at room temperature for at least 1 hour; appearance remains normal, and UVC intensity and module working current meet the drawing requirements.
10 High-temperature storage
The sample is stored at 50°C ±2°C for 72 hours and recovered at room temperature for at least 1 hour; appearance remains normal, and UVC intensity and module working current meet the drawing requirements.
11 Thermal shock
The sample cycles 10 times between −30°C ±2°C and 85°C ±2°C with 30-minute holds and a 3-minute conversion time, then recovers at room temperature for at least 1 hour; appearance, UVC intensity and working current meet the drawing requirements.
12 Constant temperature and humidity
The module is placed in a 40°C, 85% RH test chamber for 168 hours without damage, and all functions remain available.
13 Vibration test
The packaged product is tested at 4 Hz (240 CPM) for 4 hours to ISTA-2001; packaging shows no obvious damage or deformation, the product surface and parts show no mechanical damage, and product function remains normal.
14 Drop test
Packaging corners, edges and surfaces are dropped freely from a 1-metre platform; packaging, fixtures, product surfaces and parts meet the stated mechanical, electrical and appearance criteria.
15 Hazardous substances
Module hazardous-substance content is checked against the limit requirements of the EU RoHS directive.
DOCUMENT CENTER
Review the technical package for your project.
Drawings, performance reports, installation documents and market files are organized by purpose for easier project review.
APPLICATION REVIEW
Find the right EC-11 configuration for your project.
Share your peak flow, water quality and integration requirements. Our application team will match the model, configuration and supporting documents to your project.
